Description
The Sureshot is designed with a more ramp/park/trails geometry than our other frames. Utilizing a low BB, longer rear end, mellower head angle and removable brake mounts, this frame is a true all rounder.
INVEST CAST SEATCLAMP
The invest cast seatclampis brazed onto the frame so there’s no need for a separate clamp. Also the slot cut beneath the seatclamp gives more clamping powerless torque on the bolt.
INVEST CAST DROPOUTS
Becausethe dropout iscast as one piece it’s much stronger than a plate welded to a tube. 7mm thick to provide good support for your axle, and the small shape has been designedfor grinding meaning there’s no overhang tocatch on ledges or rails, also the dropout is heat treated before welding making it extra tough. And finally there’s anintegrated chain tensioner bolts inside.
INVEST CAST SEATSTAY BRIDGE
A new heat treated invest castseatstay bridge on theSureshot frame which offers a stronger and stiffer rear end.
| Toptube lengths | 20.7″ / 21″ / 21.3″ / 21.7″ |
| Headtube angle | 74.75° |
| Headtube length | 117mm |
| Seattube angle | 71° |
| Rear end length | 13.4 – 13.9″ |
| BB Height | 11.5″ |
| Standover height | 9″ |
| Weight | 5lbs |
| Brake mounts | removable – brake kit available separately |
| Tubing | Sanko Japanese seamless 4130 CrMo / triple butted |
| Headtube | Heat treated 4130 CrMo / CNC / Offset thickness |
| Bottom Bracket | Heat treated 4130 CrMo / CNC machined |
| Dropouts | Heat treated 4130 CrMo / Invest cast |
| Seatclamp | Heat treated 4130 CrMo / Invest cast |
