S&M ATF Frame For 18″ Wheels

Description

• Brake hardware sold separately

• TOP TUBE LENGTH	18.5″
  REAR END LENGTH	12.4″
  HEAD TUBE ANGLE	75°
  HEAD TUBE STYLE	Integrated (45°/45°, 41.8mm)
  SEAT TUBE ANGLE	71°
  SEAT CLAMP	Integrated
  SEAT POST SIZE	1″ (25.4mm)
  BB HEIGHT	10.5″
  BB STYLE	Mid
  STANDOVER HEIGHT	8″
  BRAKE MOUNTS	Thread-On 990 (Mounts sold separately)
  DROPOUTS	14mm Slot, 4Q-Baked
  GYRO TABS	None
  WEIGHT	4.65 lb (2.12 kg)
  TUBESET	Butted True Temper SuperTherm Tubing
