Sunday Forecaster Silva Signature Bike

Description

The Sunday Forecaster Silva Signature Bike is based off the original Forecaster line with some subtle differences for Mr. Brett Silva. Features the strong 100% chromoly frame you want, stocked with a bunch of Odyssey and Sunday goodies, including Brett’s signature seat.

Frame:Sunday Forecaster, 20.75″ TT, 100% chromoly frame with integrated 1-1/8″ head tube, and removable brake hardware
Fork:Sunday Forecaster, 20″ fork w/ 2-piece chromoly steerer tube and welded pre-load
Handlebar:Sunday, 2-piece
Stem:Sunday Freeze front load, 48mm
Headset:FSA integrated conical, 1-1/8″
Alloy Cap:Sunday M16, aluminum
Brake Lever:Odyssey Springfield
Brakes:Odyssey Springfield U-brake
Brake Cable:Odyssey Quik Slic
Grips:Odyssey Broc Raiford
Seat:Sunday Silva, Pivotal
Seatpost:Sunday Pivotal
Seat Clamp:Sunday
Sprocket:Sunday Sabertooth v2, 25T, steel
Cranks:170mm, 3-piece, chromoly
BB Parts:Sealed, Mid, 19mm
Pedals:Odyssey Twisted PC Pro
Rims:Odyssey Stage 1, 20″, 36H
Front Hub:Sunday, 36H, low-flange, sealed , 3/8″ female axle
Rear Hub: Sunday 36H, sealed cassette, 14mm male axle w/ 9T Driver
Spokes:14g steel, black
Tires:Odyssey Path Pro OEM, 20 x 2.4″ (F & R)
Chain:KMC Z1 wide
Approx. Weight: 26.78lbs (with brakes)

Frame Geometry

Top Tube Length:20.75″
Head Tube Angle:75.5°
Seat Tube Angle:71°
Chainstay Length:13.2-13.5”
Bottom Bracket Height:11.7″
Standover:9″

Handlebar Geometry

Rise:9″
Width:28.5″
Backsweep:12°
Upsweep:4°
